Product Summary
Standard Package 25PCS
Category
Fans, Thermal Management
Family
AC Fans
Series
4000N
Voltage - Rated
230VAC
Size / Dimension
Square - 119mm L x 119mm H x 38mm W
Air Flow
94.2 CFM (2.66m3/min)
Static Pressure
-
Bearing Type
Ball
Fan Type
Tubeaxial
Features
-
Noise
47 dB(A)
Power (Watts)
19.0W
RPM
2650 RPM
Termination
2 Terminals
Weight
1.2 lbs (544.3g)
Operating Temperature
-40 ~ 185°F (-40 ~ 85°C)
Current Rating
-
Life Expectancy
37500 hrs @ 40°C
Voltage Range
-
Material - Frame
Metal
Material - Blade
Metal
Associated Product
381-2536-ND - FILTER 119MM WIRE MESH METAL
LZ40/60-ND - KIT SCREEN FOR 4000, 9000 SER
LZ40N-ND - FRAME PLASTIC FOR 4000, 9000 SER
LZ30P-ND - FINGER GUARD PLAST 4000,9000 SER
381-2532-ND - FAN GUARD 119MM PLASTIC
381-2531-ND - FAN GUARD 119MM PLASTIC
381-2530-ND - FAN GUARD 119MM METAL
381-2518-ND - STEEL MOUNTING SCREW CLIP
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 4656N |
ebm-papst |
Fans & Blowers Size=119x119x38 mm CFM=94.2 VAC=230 |
Data Sheet |
|
|
||||||||||||
 |
4656NU |
ebm-papst |
Fans & Blowers ACFAN BALL BEARING 230V 47DB FLNG MT |
Data Sheet |
|
|
||||||||||||
