The HD74LS01P is a quadruple 2-input positive NAND gate.
Parametrics
HD74LS01P absolute maximum ratings: (1)input voltage, VIN: 2.0V min; VIL: 0.8V max; (2)output voltage, VOL: 0.5V max; (3)input current, IIN: 2.0μA max; IIL: -0.4mA max; II: 0.1mA max; (4)output current, IOH: 100μA max; (5)supply current, ICCN: 0.8mA typ, 1.6mA max; ICCL: 2.4mA typ, 4.4mA max; (6)input clamp voltage, VIK: -1.5V max.
Features
HD74LS01P features: (1)high level output voltage, VOH: 5.5V max; (2)low level output current, IOL: 8mA.
