Product Summary

The ISPLSI5128VE-180LT128 is an In-System Programmable High Density Logic Device, which is based on Generic Logic Blocks (GLBs) of 32 registered macrocells and a single Global Routing Pool (GRP) structure interconnecting the GLBs.

Parametrics

Absolute maximum ratings: (1)Supply Voltage Vcc: -0.5 to +5.4V; (2)Input Voltage Applied: -0.5 to +5.6V; (3)Tri-Stated Output Voltage Applied: -0.5 to +5.6V; (4)Storage Temperature: -65 to 150℃; (5)Case Temp. with Power Applied: -55 to 125℃; (6)Max. Junction Temp. (TJ) with Power Applied: 150℃.

Features

Features: (1)3.3V Power Supply; (2)User Selectable 3.3V/2.5V I/O; (3)6000 PLD Gates / 128 Macrocells; (4)96 I/O Pins Available; (5)128 Registers; (6)High-Speed Global Interconnect; (7)SuperWIDE Generic Logic Block (32 Macrocells) for; (8)Optimum Performance: SuperWIDE Input Gating (68 Inputs) for Fast Counters, State Machines, Address Decoders, etc.; (9)Interfaces with Standard 5V TTL Devices.

Diagrams

ISPL1048E-50LQ.
ISPL1048E-50LQ.
