Product Summary
The 2n7002 is an N-Channel 60-V (D-S) MOSFET.
Parametrics
2n7002 absolute maximum ratings: (1)Drain-Source Voltage VDS 60V; (2)Gate-Source Voltage—Non-Repetitive VGSM: ±40V; (3)Gate-Source Voltage-Continuous VGS: ±20V; (4)Continuous Drain Current TA= 25℃: 0.115V; TA= 100℃, ID: 0.073A; (5)Pulsed Drain Current IDM: 0.8A; (6)Power Dissipation: TA= 25℃: 0.2W; TA= 100℃: 0.08W; (7)Thermal Resistance, Junction-to-Ambient RthJA: 625℃/W; (8)Operating Junction and Storage Temperature Range TJ, Tstg: –55 to 150℃.
Features
2n7002 features: (1)Low On-Resistance: 2.5Ω; (2)Low Threshold: 2.1 V; (3)Low Input Capacitance: 22 pF; (4)Fast Switching Speed: 7 ns; (5)Low Input and Output Leakage.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 2N7002 |
Fairchild Semiconductor |
MOSFET N-CHANNEL 60V 115mA |
Data Sheet |
|
|
||||||||||||
 |
2N7002 L6327 |
Infineon Technologies |
MOSFET N-KANAL SML SIG MOS |
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002 LTI |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002 T&R 3000 PCS |
Central Semiconductor |
MOSFET N-Ch 5V .2A |
Data Sheet |
Negotiable |
|
||||||||||||
|
2N7002(Z) |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002,215 |
NXP Semiconductors |
MOSFET N-CH TRNCH 60V 300MA |
Data Sheet |
|
|
||||||||||||
|
2N7002\E9 |
Vishay Semiconductors |
MOSFET SOT-23 N-CH 60V 0.25 |
Data Sheet |
Negotiable |
|
||||||||||||
 |
2N7002_D87Z |
Fairchild Semiconductor |
MOSFET N-Ch Enhancement Mode Field Effect |
Data Sheet |
|
|
||||||||||||
