Product Summary

The TPSB106M016R0800 is a tantalum capacitor, which has inherently low ESR (equivalent series resistance)and is capable of higher ripple current handling, producing lower ripple voltages, less power and heat dissipation than standard product for the most efficient use of circuit power. The TPSB106M016R0800 has been designed, manufactured, and preconditioned for optimum performance in typical power supply applications.

Parametrics

TPSB106M016R0800 technical specifications: (1)Capacitance Range: 0.15 μF to 1500 μF; (2)Capacitance Tolerance: ±10%; ±20%; (3)Rated Voltage (VR) ≤ +85℃: 10V; (4)Category Voltage (VC) ≤ +125℃: 7V; (5)Surge Voltage (VS) ≤ +85℃: 13V; (6)Surge Voltage (VS) ≤ +125℃: 8V; (7)Temperature Range: -55℃ to +125℃; (8)Environmental Classification: 55/125/56 (IEC 68-2); (9)Reliability: 1% per 1000 hours at 85℃, VR with 0.1Ω/V series impedance, 60% confidence level; (10)Termination Finished: Sn Plating (standard), Gold and SnPb Plating upon request.

Features

TPSB106M016R0800 features: (1)Low ESR series of robust Mn02 solid electrolyte capacitors; (2)CV range: 0.15-1500μF/ 2.5-50V; (3)14 case sizes available; (4)Power supply applications.

Diagrams

TPSB106M016R0800 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TPSB106M016R0800
TPSB106M016R0800

AVX

Tantalum Capacitors - Solid SMD 10UF 16V 20% B

Data Sheet

0-1: $0.60
1-10: $0.51
10-100: $0.30
100-500: $0.23
